WASHINGTON

WASHINGTON is an IP54 rated wide beam downlight for commercial applications. The IP54 rating makes it suitable not only for corridors and stairwells, but also for toilets, changing rooms and under-canopy applications. WASHINGTON is available in 3 wattages (12W, 20W & 30W) with efficiency up to 138 l.lm/c.W, and a full range of dimming and emergency options. WASHINGTON has a shallow recessed TP(a) rated diffuser, giving a wide beam angle of 100° so that very high levels of uniformity can be achieved easily.

WESTMINSTER

WESTMINSTER is an IP54 rated low glare downlight for commercial applications. The IP54 rating makes it suitable not only for corridors and stairwells, but also for toilets, changing rooms and under-canopy applications. WESTMINSTER is available in 3 wattages (12W, 20W & 30W) with efficiency up to 122 l.lm/c.W, and a full range of dimming and emergency options. The construction of WESTMINSTER, with its deep-recessed TP(a) rated diffuser, means that in most applications the UGR will be <21, while the medium beam angle of 65° means that high levels of uniformity can be achieved. Because WESTMINSTER is supplied with a L, E & N loop-in/loop-out piano-key terminal block it is quick to install and does not require a separate junction box.

LINCOLN

The LINCOLN is an IP40, backlit LED panel. It has a TP(a) rated micro-prismatic controller for UGR<19 compliant lighting schemes. Supplied with a high-quality, ENEC approved, flicker free driver, NVC’s LINCOLN panel is available in 3 wattages: 18W, 28W and 35W, all with a CCT of 4000K. Emergency versions are available by using our plug and play emergency conversion packs (standard or self-test, both ordered as separate items). Other options available include DALI addressable emergency, and dimming options. NVC’s LINCOLN LED panel is ideal for lighting offices, corridors, and a wide range of commercial spaces.

DALLAS

The DALLAS is a stylish yet robust surface/suspended luminaire. DALLAS is available as downlight only, or bi-directional, with 70% downlight and 30% uplight. It is available in 4’ and 5’ lengths, each length is available in 2 wattages and with an opal diffuser or a louvre. DALLAS fittings can be joined together to form a variety of shapes, including straight lines, Xs, Ls or Ts. Emergency and dimming variants are available. DALLAS is widely used for lighting in corridors, schools, colleges, and many public sector applications.

GREENLAND

The Greenland is a high quality, IK10, IP66 rated, non-corrosive, impact and chemical resistant, industrial LED luminaire. This luminaire has a polycarbonate base, polycarbonate opal diffuser, grade 316 stainless steel clips, and can also be suspended from wire/chain suspension kits. It comes with an ENEC approved integrated flicker free driver NVC’s Greenland is available in four single and twin sizes; 2Ft, 4Ft, 5Ft and 6Ft, and comes with a CCT of either 4000K or 5000K. As well as the standard and emergency M3 versions, there are options to have specialist emergency such as DALI addressable or automatic self-test, DALI dimmable, corridor function and integral microwave or batten mount PIR sensors. NVC’s Greenland is ideal for lighting car parks, garages, workshops and general industrial use. Greenland Led Luminaire can be used with MyMesh Smart Lighting Control Solutions

JUPITER

JUPITER is a high-performance high-bay with a wide range of outputs, options and attachments.

Three wattages are available, 100W, 150W and 200W, with efficiency up to 167 llm/cW.

1-10V dimming is supplied as standard, but its use is optional. Other options include emergency and a plug-in microwave sensor. Refractors, reflectors and a stirrup mounting bracket are also available.
